Lenovo ThinkPad P1 Gen 7 Mobile Workstation

Technical Architecture Summary

CPU Family: Intel Core Ultra 9 185H
Max Graphics TGP: 130W TGP
RAM Upgradability: ✅ Upgradable
Battery / Weight: 90 Wh / 1.82 kg

ZERO-PRICING STANDARD:OPA Specs exclusively indexes verified empirical engineering metrics, thermal dissipation data, and factory datasheets. No volatile retail pricing or affiliate markup.

Compare Side-by-Side →Jump to Full Spec Matrix ↓

Comprehensive Hardware Specification Matrix

Direct engineering breakdown categorized by compute, display, thermal envelope, I/O, and chassis acoustics.

01.Platform & Compute Architecture

Processor / SoC: Intel Core Ultra 9 185H (vPro Enterprise, Intel AI Boost NPU)
CPU Core Configuration: 16-core / 22-thread (up to 5.1 GHz Max Turbo)
Instruction Set: x86_64
Graphics Subsystem: NVIDIA GeForce RTX 4080 Laptop GPU (12GB GDDR6) or RTX 3500 Ada Generation (12GB)
Max Graphics TGP: 130 Watts
AI NPU Acceleration: 11 TOPS
Operating System: Windows 11 Pro / Red Hat Enterprise Linux / Ubuntu certified

02.Memory & Storage Upgradability

RAM Capacity Options: 16 GB / 32 GB / 64 GB LPCAMM2 (Upgradable modular LPDDR5X)
RAM Technology / Clock: LPCAMM2 LPDDR5X-7467 MT/s (World-first modular low-power RAM)
Memory Upgradability: Yes (User-Upgradable)
Memory Sockets / Form Factor: 1x LPCAMM2 socket (User-swappable up to 64GB)
Base NVMe Capacity: 1024 GB
M.2 Expansion Slots: 2 Slots
Storage Bus & Type: 2x M.2 2280 PCIe 4.0 x4 NVMe SSD slots with copper heatspreaders

03.Display & Color Accuracy

Display Panel Technology: OLED
Screen Diagonal Size: 16 inches
Aspect Ratio: 16:10
Native Resolution: 3840 × 2400 px (4K WQUXGA OLED Touch, DisplayHDR True Black 600)
Refresh Rate: 60 Hz
Color Gamut Calibration: 100% DCI-P3, Factory X-Rite Color Calibration
Peak Brightness: 500 nits

04.Chassis, Thermals & Battery

Weight: 1.82 kg (4 lbs)
Thickness: 17.05 mm
Chassis Materials: Liquid-cast magnesium bottom chassis with carbon-fiber reinforced polymer A-cover
Thermal Architecture: Liquid metal thermal paste + Dual high-flow centrifugal fans + Full vapor chamber
Battery Capacity: 90 Watt-hours
Bundled Adapter Wattage: 170 W
USB-C Power Delivery Input: Yes (Up to 140W)

05.I/O Ports & Wireless Connectivity

Port Complement

2x Thunderbolt 4 (USB4 40 Gbps), 1x USB-C 3.2 Gen 2 (10 Gbps), 1x USB-A 3.2 Gen 1, HDMI 2.1, Full-size SD Express 7.0 reader, 3.5mm audio jack, Lenovo Slim-tip power

Thunderbolt / USB4

2x Thunderbolt

HDMI: HDMI 2.1 (8K60 or 4K120)

Card Reader & Audio

Full-size SDXC Card Reader

3.5mm Headphone Jack: ✅ Present

Wireless Subsystem

Intel Wi-Fi 7 BE200 802.11be, Bluetooth 5.4, Optional 4G/5G
