Apple MacBook Pro 16 (M4 Max Titan)

Technical Architecture Summary

CPU Family: Apple M4 Max
Max Graphics TGP: 55W TGP
RAM Upgradability: Soldered Onboard
Battery / Weight: 100 Wh / 2.14 kg

ZERO-PRICING STANDARD:OPA Specs exclusively indexes verified empirical engineering metrics, thermal dissipation data, and factory datasheets. No volatile retail pricing or affiliate markup.

Compare Side-by-Side →Jump to Full Spec Matrix ↓

Comprehensive Hardware Specification Matrix

Direct engineering breakdown categorized by compute, display, thermal envelope, I/O, and chassis acoustics.

01.Platform & Compute Architecture

Processor / SoC: Apple M4 Max (TSMC 3nm N3E, 546 GB/s memory bandwidth, Apple Intelligence Engine)
CPU Core Configuration: 16-core (12 performance cores + 4 efficiency cores)
Instruction Set: ARM
Graphics Subsystem: Apple 40-core GPU with 2x hardware ray tracing engine & Dynamic Caching
Max Graphics TGP: 55 Watts
AI NPU Acceleration: 38 TOPS
Operating System: macOS Sequoia

02.Memory & Storage Upgradability

RAM Capacity Options: 36 GB / 48 GB / 64 GB / 128 GB Unified Memory
RAM Technology / Clock: LPDDR5X-8533 MHz (546 GB/s memory bandwidth)
Memory Upgradability: No (Soldered Onboard)
Memory Sockets / Form Factor: Unified Package Memory
Base NVMe Capacity: 1024 GB
M.2 Expansion Slots: 0 Slots
Storage Bus & Type: Ultra-fast soldered PCIe 4.0 flash storage array

03.Display & Color Accuracy

Display Panel Technology: Mini-LED
Screen Diagonal Size: 16.2 inches
Aspect Ratio: 16:10
Native Resolution: 3456 × 2234 px (254 ppi Liquid Retina XDR with Nano-texture option)
Refresh Rate: 120 Hz
Color Gamut Calibration: 100% DCI-P3 wide color, 1,000 nits SDR / 1,600 nits HDR
Peak Brightness: 1600 nits

04.Chassis, Thermals & Battery

Weight: 2.14 kg (4.7 lbs)
Thickness: 16.8 mm
Chassis Materials: 100% Recycled aluminum unibody enclosure in Space Black
Thermal Architecture: Dual asymmetric impellers with advanced vapor thermal dissipation
Battery Capacity: 100 Watt-hours
Bundled Adapter Wattage: 140 W
USB-C Power Delivery Input: Yes (Up to 140W)
