OFFICIAL FACTORY PACKSHOT•PURE WHITE STUDIO ISOMETRIC
Applecreatorx86_64 ARCHITECTURE2016
Apple MacBook Pro 15 (2016 Touch Bar)
Technical Architecture Summary
- CPU Family
- Intel Core i7-6700HQ / i7-6820HQ
- Max Graphics TGP
- 35W TGP
- RAM Upgradability
- Soldered Onboard
- Battery / Weight
- 76 Wh / 1.83 kg
ZERO-PRICING STANDARD:OPA Specs exclusively indexes verified empirical engineering metrics, thermal dissipation data, and factory datasheets. No volatile retail pricing or affiliate markup.
Comprehensive Hardware Specification Matrix
Direct engineering breakdown categorized by compute, display, thermal envelope, I/O, and chassis acoustics.
01.Platform & Compute Architecture
- Processor / SoC
- Intel Core i7-6700HQ / i7-6820HQ (Skylake 14nm)
- CPU Core Configuration
- 4-core / 8-thread (2.6 GHz base, 3.5 GHz Turbo)
- Instruction Set
- x86_64
- Graphics Subsystem
- AMD Radeon Pro 450 / 455 (2GB GDDR5) or Radeon Pro 460 (4GB GDDR5)
- Max Graphics TGP
- 35 Watts
- Operating System
- macOS Sierra
02.Memory & Storage Upgradability
- RAM Capacity Options
- 16 GB LPDDR3 (Soldered)
- RAM Technology / Clock
- LPDDR3-2133 MHz
- Memory Upgradability
- No (Soldered Onboard)
- Memory Sockets / Form Factor
- Soldered Onboard
- Base NVMe Capacity
- 256 GB
- M.2 Expansion Slots
- 0 Slots
- Storage Bus & Type
- Apple soldered PCIe 3.0 NVMe storage array
03.Display & Color Accuracy
- Display Panel Technology
- IPS LCD
- Screen Diagonal Size
- 15.4 inches
- Aspect Ratio
- 16:10
- Native Resolution
- 2880 × 1800 px (220 ppi)
- Refresh Rate
- 60 Hz
- Color Gamut Calibration
- 100% DCI-P3 wide color gamut
- Peak Brightness
- 500 nits
04.Chassis, Thermals & Battery
- Weight
- 1.83 kg (4 lbs)
- Thickness
- 15.5 mm
- Chassis Materials
- All-metal aluminum unibody, Force Touch glass trackpad
- Thermal Architecture
- Split dual-fan system with thin blades
- Battery Capacity
- 76 Watt-hours
- Bundled Adapter Wattage
- 87 W
- USB-C Power Delivery Input
- Yes (Up to 87W)
05.I/O Ports & Wireless Connectivity
Port Complement
4x Thunderbolt 3 (USB-C 40 Gbps, DisplayPort, Charging), 3.5mm headphone jack, OLED Touch Bar with Touch ID
Thunderbolt / USB4
4x Thunderbolt
HDMI: None (Native DisplayPort over USB-C / HDMI via dongle)Card Reader & Audio
None Card Reader
3.5mm Headphone Jack: ✅ PresentWireless Subsystem
802.11ac Wi-Fi, Bluetooth 4.2
