Microsoft Surface Pro 11 (OLED Copilot+ 2-in-1)

Technical Architecture Summary

CPU Family: Qualcomm Snapdragon X Elite X1E-80-100
Max Graphics TGP: 25W TGP
RAM Upgradability: Soldered Onboard
Battery / Weight: 53 Wh / 0.895 kg

ZERO-PRICING STANDARD:OPA Specs exclusively indexes verified empirical engineering metrics, thermal dissipation data, and factory datasheets. No volatile retail pricing or affiliate markup.

Compare Side-by-Side →Jump to Full Spec Matrix ↓

Comprehensive Hardware Specification Matrix

Direct engineering breakdown categorized by compute, display, thermal envelope, I/O, and chassis acoustics.

01.Platform & Compute Architecture

Processor / SoC: Qualcomm Snapdragon X Elite X1E-80-100 (4nm Oryon 12-core ARM, 45 TOPS NPU)
CPU Core Configuration: 12-core Oryon CPU (up to 4.0 GHz boost)
Instruction Set: ARM
Graphics Subsystem: Qualcomm Adreno GPU (3.8 TFLOPS FP32)
Max Graphics TGP: 25 Watts
AI NPU Acceleration: 45 TOPS
Operating System: Windows 11 Home Copilot+ PC Edition

02.Memory & Storage Upgradability

RAM Capacity Options: 16 GB / 32 GB LPDDR5X (Soldered)
RAM Technology / Clock: LPDDR5X-8448 MT/s
Memory Upgradability: No (Soldered Onboard)
Memory Sockets / Form Factor: Soldered Onboard
Base NVMe Capacity: 512 GB
M.2 Expansion Slots: 1 Slot
Storage Bus & Type: 1x Removable M.2 2230 PCIe 4.0 x4 SSD slot under kickstand hatch

03.Display & Color Accuracy

Display Panel Technology: OLED
Screen Diagonal Size: 13 inches
Aspect Ratio: 3:2
Native Resolution: 2880 × 1920 px (267 ppi PixelSense Flow OLED, 120Hz dynamic VRR)
Refresh Rate: 120 Hz
Color Gamut Calibration: 100% DCI-P3, 1,000,000:1 contrast ratio, Dolby Vision IQ
Peak Brightness: 900 nits

04.Chassis, Thermals & Battery

Weight: 0.895 kg (2 lbs)
Thickness: 9.3 mm
Chassis Materials: Anodized aluminum with 165-degree friction kickstand and detachable Surface Pro Flex Keyboard
Thermal Architecture: Vapor chamber passive hybrid with low-noise ultra-thin blower fan
Battery Capacity: 53 Watt-hours
Bundled Adapter Wattage: 39 W
USB-C Power Delivery Input: Yes (Up to 65W)
